Manual Tray Sealer Stainless Steel VS300
VS300 Tray Sealing Machine
The VS Range of tabletop lidding machines is manufactured in the UK. They have been designed specifically for use with heat sealable food trays and sandwich wedges. These stainless steel machines feature either fixed or adjustable temperature control, Teflon coated non stick sealing plate, twin roll film supports with guide rings and twin gas spring head lift.
VS300 Standard Dial: Maximum Tray Size:- 190 x 250mm
VS Range for For Sealing Trays
The VS range is perfect for sealing Lidding Film to suitable trays and is supplied with a die plate custom made for the tray to be sealed, with additional die plates available upon request. The trays are sealed with either a peelable film or a sealable (welded) film. The machines will work with all types of sealable food trays and films up to a maximum width of 190mm.
VS Range For Sealing Cardboard Sandwich Wedges
The VS range is perfect for sealing Cardboard Sandwich Wedges, the machine is supplied with a die plate custom made for the wedge to be sealed, with additional die plates available upon request.
Please note the following:-
VS200 Die Plate will have 1 cavity for sealing 1 sandwich wedge per cycle
VS300/VS300DT Die Plates will have 2 cavities for sealing 2 sandwich wedges per cycle
The machine is switched on and the required temperature set, when the temperature has been reached, the film which is mounted at the back of the machine on two support rollers is pulled over the top of the tray to be sealed which had been placed in the die plate. The sealing head is then lowered by hand and pressed down to seal the film to the tray, at the same time the film is cut from the main roll. The sealing head is then raised to the open position and the tray removed.
The VS type of tray sealing machine installations are typically found in supermarkets, local butchers, and grocers shops producing ready meals, fresh and cooked meats, fish, and vegetables.
VS200 – Fixed temperature control
VS300 – Standard Dial or Digital Control models available
Teflon coated sealing plate
Stainless steel fabrication
Twin reel film supports
Quick change die plates (no tools required)
No installation required – Just plugin, allow 10 minutes to heat up, and start sealing your trays!
Tray Sealer Lidding Machine VS300 With Adjustable Temperature And Die Plate: Sealing Area 190x150mm
